3D Shadowing and display Object Color by Layer.3D STEP export of complete board assemblies.3D STEP file import for component bodies.Altium Designer 6.9 takes Altium Designer 6.8 one step further, building on market-leading features such as real-time 3D PCB visualization and introducing powerful new features such as programmable technology support and system connectivity. The best approach is to look at the functional requirements first as these can limit your component and circuit choices.Altium continues to deliver electronics design tools that break the mould, with the latest release – Altium Designer 6.9. The term “requirements” in a PCB design project can refer to functional requirements, as well as the component or circuit requirements. Other times, when you have to do all the front-end engineering work, you’ll have to develop the requirements yourself. If you’re working as a professional designer at an engineering services company or at an OEM, it’s possible that someone will give you a list of requirements in the project.
Gathering Requirementsīefore starting any PCB design and layout project, the first thing to do is to gather the basic requirements that will govern how the design and layout are created. The connections through the pin headers will be used to give power to the main Arduino Uno board and to hold the shield board.Īn Arduino Uno (bottom board) and an attached shield board. The board you’ll design is sometimes called a shield board, meaning it sits on top of the standard Arduino Uno board and makes connections through standard pin headers. The fun twist to this project is that the board will also provide power to an Arduino Uno, which will bypass some of the main power controller functions on the Arduino in favor of the regulator you’ll design. In this project, you’ll be designing a power regulator board that powers a bank of LEDs. Welcome to the Altium Education guided project! In this project, you’ll have a chance to see the entire process for designing a PCB, including some basic engineering tasks used to help prepare the design and start the PCB layout.
